Multipurpose Threaded Swivel Air Fittings

This ferulok 24 Degrees flareless fitting meets the standards for ASTM B117, ISO 8434-3, ISO 9227, SAE J1453, has a maximum operating pressure of 5,000 psi and is designed for the following applications: gas handling connections and hydraulic fluid. It is resistant to corrosion and is made of steel. In addition, it is a straight, with an imperial system of measurement. Plus, it has a ⅞ inch hex size.

This ferulok 24 Degrees flareless fitting meets the standards for ASTM B117, ISO 8434-3, ISO 9227, SAE J1453, has a maximum operating pressure of 5,000 psi and is designed for the following applications: gas handling connections and hydraulic fluid. It is resistant to corrosion and is made of steel. In addition, it is a straight, with an imperial system of measurement. Plus, it has a ⅞ inch hex size.

This Seal-Lok O-ring face seal tube fitting and adapter meets the standards for ISO 8434-3, SAE J1453, has a length of 2.3 inch, a maximum operating pressure of 9,200 psi and is designed for the following applications: hydraulic fluid and gas handling connections. It is made of steel with a Toughshield Plus plating finish/coating. In addition, it is a connector. Plus, it has a 1¾ inch hex size. This Seal-Lok O-ring face seal tube fitting and adapter includes a seal.

This Seal-Lok O-ring face seal tube fitting and adapter meets the standards for ISO 8434-3, SAE J1453, has a length of 2.3 inch, a maximum operating pressure of 9,200 psi and is designed for the following applications: hydraulic fluid and gas handling connections. It is made of steel with a Toughshield Plus plating finish/coating. In addition, it is a connector. Plus, it has a 1¾ inch hex size. This Seal-Lok O-ring face seal tube fitting and adapter includes a seal.

This is a male elbow connector.

This is a male elbow connector.

For use with all hydraulic application fluids, featuring 1/2" 37 Degrees JIC flare (3/4"-16 thread) at one end, and 3/8" ORB (9/16"-18 thread) at the other and a male-to-male connection.

For use with all hydraulic application fluids, featuring 1/2" 37 Degrees JIC flare (3/4"-16 thread) at one end, and 3/8" ORB (9/16"-18 thread) at the other and a male-to-male connection.

This straight swivel connector allows your hose coupling and connection to rotate in order to prevent twisting, kinking, and bending. Hose fitting A is male with a 3/8"-18 thread size, and a NPTF connection type. Hose fitting B has a 3/4"-16 37 Degrees swivel connection type. This fitting has an overall length of 1.74 inches.

This straight swivel connector allows your hose coupling and connection to rotate in order to prevent twisting, kinking, and bending. Hose fitting A is male with a 3/8"-18 thread size, and a NPTF connection type. Hose fitting B has a 3/4"-16 37 Degrees swivel connection type. This fitting has an overall length of 1.74 inches.

This straight swivel connector allows your hose coupling and connection to rotate in order to prevent twisting, kinking, and bending. Hose fitting A is male with a 1/2"-14 thread size, and a NPTF connection type. Hose fitting B has a 7/8"-14 37 Degrees swivel connection type. This fitting has an overall length of 2.05 inches.

This straight swivel connector allows your hose coupling and connection to rotate in order to prevent twisting, kinking, and bending. Hose fitting A is male with a 1/2"-14 thread size, and a NPTF connection type. Hose fitting B has a 7/8"-14 37 Degrees swivel connection type. This fitting has an overall length of 2.05 inches.

This Seal-Lok O-ring face seal tube fitting and adapter meets the standards for ISO 8434-3, SAE J1453, has a length of 51.5 mm, a maximum operating pressure of 9,200 psi and is designed for the following applications: hydraulic fluid and gas handling connections. It is made of steel with a Toughshield Plus plating finish/coating has a 41 mm hex size. This Seal-Lok O-ring face seal tube fitting and adapter includes a seal.

This Seal-Lok O-ring face seal tube fitting and adapter meets the standards for ISO 8434-3, SAE J1453, has a length of 51.5 mm, a maximum operating pressure of 9,200 psi and is designed for the following applications: hydraulic fluid and gas handling connections. It is made of steel with a Toughshield Plus plating finish/coating has a 41 mm hex size. This Seal-Lok O-ring face seal tube fitting and adapter includes a seal.

This female connection tube joins 1/2" 37 Degrees JIC flare, 3/4"-16 thread to 3/4"-14 thread NPTF, and fits into thread tube end measuring 3/4"-16 thread with a 1 3/8" hex. Engineered for use in all hydraulic fluid systems.

This female connection tube joins 1/2" 37 Degrees JIC flare, 3/4"-16 thread to 3/4"-14 thread NPTF, and fits into thread tube end measuring 3/4"-16 thread with a 1 3/8" hex. Engineered for use in all hydraulic fluid systems.

Connecting 1/4 inch 37 Degrees JIC flare with 1/4"-18 thread NPTF, this female connector fits into tube end measuring 7/16"-20 thread UN/UNF-2A with a hex size of 3/4 inches. For use in all hydraulic fluid applications.

Connecting 1/4 inch 37 Degrees JIC flare with 1/4"-18 thread NPTF, this female connector fits into tube end measuring 7/16"-20 thread UN/UNF-2A with a hex size of 3/4 inches. For use in all hydraulic fluid applications.

Male-to-male adapter for straight pipe, 3/8 inch JIC (9/16"-18 thread) on one end and 5/16 inch ORB (1/2"-20 thread) on the other end. For use in hydraulic operations.

Male-to-male adapter for straight pipe, 3/8 inch JIC (9/16"-18 thread) on one end and 5/16 inch ORB (1/2"-20 thread) on the other end. For use in hydraulic operations.

This Seal-Lok O-ring face seal tube fitting and adapter meets the standards for ISO 8434-3, SAE J1453, has a length of 41.9 mm, a maximum operating pressure of 9,200 psi and is designed for the following applications: hydraulic fluid and gas handling connections. It is made of steel with a Toughshield Plus plating finish/coating has a 32 mm hex size. This Seal-Lok O-ring face seal tube fitting and adapter includes a seal.

This Seal-Lok O-ring face seal tube fitting and adapter meets the standards for ISO 8434-3, SAE J1453, has a length of 41.9 mm, a maximum operating pressure of 9,200 psi and is designed for the following applications: hydraulic fluid and gas handling connections. It is made of steel with a Toughshield Plus plating finish/coating has a 32 mm hex size. This Seal-Lok O-ring face seal tube fitting and adapter includes a seal.

This Seal-Lok O-ring face seal tube fitting and adapter meets the standards for ISO 8434-3, SAE J1453, has a length of 49.8 mm, a maximum operating pressure of 9,200 psi and is designed for the following applications: hydraulic fluid and gas handling connections. It is made of steel with a Toughshield Plus plating finish/coating has a 41 mm hex size. This Seal-Lok O-ring face seal tube fitting and adapter includes a seal.

This Seal-Lok O-ring face seal tube fitting and adapter meets the standards for ISO 8434-3, SAE J1453, has a length of 49.8 mm, a maximum operating pressure of 9,200 psi and is designed for the following applications: hydraulic fluid and gas handling connections. It is made of steel with a Toughshield Plus plating finish/coating has a 41 mm hex size. This Seal-Lok O-ring face seal tube fitting and adapter includes a seal.

This flare tube fitting meets the standards for SAE 071720 and has a length of 2.08 inch. In addition, it is a straight adapter.

This flare tube fitting meets the standards for SAE 071720 and has a length of 2.08 inch. In addition, it is a straight adapter.

Connect pipes and hoses with this male connector. This male connector has a chromium-6 free finish, and meets SAE J514 and ISO 8434-2 standards.

Connect pipes and hoses with this male connector. This male connector has a chromium-6 free finish, and meets SAE J514 and ISO 8434-2 standards.

Straight run male-to-male connector, 3/4 inch JIC (1 1/16"-12 thread) and 1 inch ORB (1 5/16"-12 thread) passing mineral or petroleum based liquids in the hydraulics environment.

Straight run male-to-male connector, 3/4 inch JIC (1 1/16"-12 thread) and 1 inch ORB (1 5/16"-12 thread) passing mineral or petroleum based liquids in the hydraulics environment.

Straight connector, male ends on both, fits to 1/4 inch JIC (7/16"-20 thread) and 1/4 inch ORB (7/16"-20 thread) that run petroleum or mineral fluids in hydraulic applications.

Straight connector, male ends on both, fits to 1/4 inch JIC (7/16"-20 thread) and 1/4 inch ORB (7/16"-20 thread) that run petroleum or mineral fluids in hydraulic applications.
