TUBING: POLYURETHANE, INSIDE DIAMETER ¼ IN, OUTSIDE DIAMETER ⅜ IN, 100 FT LG, BLUE
TUBING: POLYURETHANE, INSIDE DIAMETER ¼ IN, OUTSIDE DIAMETER ⅜ IN, 100 FT LG, BLUE
APPROVED VENDOR
close
close x
images.360.info.textHead1
360°
images.360.info.textHead2
Rotate: Use top-to-bottom, side-to-side by use of mouse arrow.
Zoom In: Double click on image.
Zoom Out/Reset: Put photo at full zoom & then double click.
Roll over image to zoom.
Product Details
This tubing has a length of 100 feet, a maximum operating pressure of 150 psi and is designed for the following applications: air, water. It is blue, has an operating temperature of -68 Degrees F to 140 Degrees F and is resistant to abrasion, wear and is made of polyurethane. In addition, it has ⅜ inch outside diameter, ¼ inch inside diameter, with an inch system of measurement, with 0.06 inch wall thickness, and Shore A 98 hardness.
Technical Specs
Item Tubing Colour Blue Inside Diameter 1/4 in Jacket Material No Jacket Maximum Operating Pressure 150 psi Outside Diameter 3/8 in Peristaltic Pump Compatible Not Peristaltic Pump Compatible Reinforcement Not Reinforced Food and Beverage Compatibility Non-Potable Water Bend Radius 1 1/2 in Fitting Compatibility Push-to-Connect Stripe Colour No Stripe Tube Form Coil Burst Pressure 150 psi Minimum Operating Temperature -68 Degrees F
Application Air, Water Hardness Shore A 98 Jacket Colour No Jacket Material Polyurethane Maximum Operating Temperature 140 Degrees F Overall Length 100 ft Resistance Properties Abrasion Resistant, Wear Resistant Wall Thickness 0.06 in Autoclavable Autoclavable Clarity Semi-Clear Flexibility Flexible System of Measurement Inch Vacuum Rated Not Rated for Vacuum Flow Application Air and Water Lines, Carwash and Painting Equipment, Robotics Country of Origin Taiwan
(subject to change)
