COMPOUND GAUGE ,4-1/2" DIAL SIZE
COMPOUND GAUGE ,4-1/2" DIAL SIZE
DURO
close
close x
images.360.info.textHead1
360°
images.360.info.textHead2
- Rotate: Use top-to-bottom, side-to-side by use of mouse arrow.
- Zoom In: Double click on image.
- Zoom Out/Reset: Put photo at full zoom & then double click.
Roll over image to zoom.
Technical Specs
- ItemIndustrial Compound Gauge
- Accuracy+/-0.5%
- Process Connection TypeNPT
- Lens MaterialGlass
- Field FillableNo
- Case ColourChrome
- Primary Pressure Range30 to 0 to 60
- Vibration ResistanceNone
- Pressure Gauge TypeIndustrial Pressure Gauge
- Gauge Case LiquidNone
- Socket MaterialStainless Steel
- Accuracy GradeASME B40.100 Grade 2A
- ApplicationChemical Industries, Oil and Gas Industry
- Accuracy ScaleFull Scale
- Bezel Mounting TypeBayonet
- Case ConstructionCorrosion Resistant
- Case Diameter5.04 in
- Dial Face MaterialAluminum
- Hazardous Location RatingNot Rated
- Includes Mounting HardwareNo
- Manufacturer Warranty Length1 yr
- Movement MaterialStainless Steel
- Non-SparkingNo
- Pressure Range TypeCompound
- Removable BezelYes
- Secondary Pressure Range0 to 4
- Sensor TypeBourdon Tube
- Nominal Dial Size 4 1/2 in
- Gauge Case Material Stainless Steel
- Process Connection Gender Male
- Process Connection Size 1/4 in
- Process Connection Location Bottom
- IP/NEMA Rating Not Rated
- Dry Dampening Feature None
- Dial Colour White
- Liquid-Filled Case No
- Panel-Mountable No
- Sensor Material Stainless Steel
- Series Series 20
- Primary Scale Units in Hg/psi
- Ambient Operating Temperature Range -30 Degrees to 250 Degrees F
- Blowout Safety Back No
- Case Depth 2.32 in
- Cleaned for Oxygen Service No
- Freeze Resistant Movement No
- Includes Calibration Certificate No
- Includes Vent Plug No
- Mounting Type Back Flange
- Movement Type Rotary
- Pointer Characteristics Lightweight Balanced Construction with Micrometer Adjustment
- Primary Scale Minor Graduations 1
- Scale Type Dual
- Secondary Scale Units bar
- Standards ASME/ANSI
- Country of Origin United States
